Home in Texas on the Drawloom

The sky is the limit! That is my conclusion after weaving a few designs using the Myrehed combination drawloom. The shaft draw and the single unit draw systems are combined on this ingenious apparatus that is attached to an otherwise ordinary loom. The shaft draw system enables me to weave repeated patterns. The single unit system enables non-repeat patterns. This narrow warp is my playground to do both.

Myrehed Combination drawloom - learning its potential.
Pattern shafts (the wood bars) and single units (with black and white draw cords) are combined for this warp. 36 pattern shafts, including the X shaft. 132 single units.
Setting up the Myrehed combination drawloom.
Central design area uses a repeat of 30 pattern shafts threaded in a straight draw. Side borders use a repeat of 5 pattern shafts. Lift heddles and lanyard clips on the single unit draw cords attach the draw cords to the all the individual units (single units) on the pattern shafts.

I use the computer to create designs. ”Home in Texas” shows the back of our house, with its massive stone chimney. The tree in the scene is a tracing of the oak tree that I pass as I walk up the hill to my drawloom studio. The airplane is a copy of the Mooney that our pilot friend took us in to fly over Enchanted Rock. I am delighted to discover that I can use a drawloom to bring features of personal meaning such as these to life.

Making a gridded pattern for weaving on the drawloom.
Photo of our back deck. Using Affinity Photo, I set up a grid on the page to represent 30 pattern shafts. I then import my photo onto the gridded page.
Creating a simple gridded pattern on the computer.
Simple outline is created and saved as a separate image. The filled-in outline becomes my drawloom pattern.
Creating gridded designs in Affinity Photo.
Oak tree that I pass on the hill up to my drawloom studio. After importing the photo, I adjust the opacity to fade the picture, which makes tracing easier.
Tracing a tree in Affinity Photo to make a drawloom pattern.
I use a pen tool in Affinity Photo set at 3 pt to do the tracing. Now I can fill in the outline and copy and paste the image onto my chart that I will print and then use at the loom.
Drawloom weaving, using the Myrehed Combination.
Houses are woven with 30 pattern shafts. The hearts in the corners and the added details above the houses use the single unit draw cords. The tree is beginning to appear between the two houses on the left.
Myrehed Combination drawloom.
Two draw handles are pulled for the pattern on the side borders. Single unit draw cords are pulled and held in place on the hook bar above the beater.
Our Texas Home - woven on the drawloom.
Our Texas Home

The words of the Creator have life in them. It’s as if he puts his thoughts on the loom and weaves them into being. Let there be light! He speaks; and it is so. Listen closely. Hear the Grand Weaver say, Peace to you. And it is woven so. You are his workmanship, bringing his design to life.

Experimental warp on the drawloom.
More ideas are forming, even as this fabric begins to hug the cloth beam.

May your life reveal the Creator’s design.

Happy Weaving,
Karen

25 Comments

  • Kelly says:

    Wow, that is amazing!

  • Beth Mullins says:

    Mind blown! Wow!

    • Karen says:

      Hi Beth, The drawloom attachment changes everything. At the root of it all, though, is normal weaving. The draw handles and cords turn it into a giant counted cross stitch machine. 🙂

      Happy weaving,
      Karen

  • Wanda says:

    Fabulous! I love seeing what you weave!

  • Judy Goodwin says:

    I took a drawloom class at Vavstuga Studios in MA. I loved being able to create the designs. Would love to do more of it. Your work is wonderful

    • Karen says:

      Hi Judy, That’s great that you had the drawloom experience at Vavstuga. I’m sure it was wonderful! Creating the designs on the computer has been quite a learning curve for me. I’m beginning to enjoy it. 🙂

      Thank you,
      Karen

  • Kevin B says:

    Ah, so much to learn! As always your weaving is beautiful and very inspirational! Thank you for sharing!

  • Betsy says:

    Oh, wow!! Very cool.

  • Charlene says:

    There is a great deal more than the threads of fibre weaving through your blog posts and the story of your art. I catch a thread or two, sometimes in what you write; “May your life reveal the Creator’s design” and sometimes in the comments; “May I add, amen.”

    Comparatively, I find my own weaving journey so intimidatingly small as I read about your journey, but then I remember the joy isn’t in comparison, the joy is in our created uniqueness.

    It is fascinating – both in this created life God has given us and to share your unique contribution with you. Thank you for such detail in both photo and description. I thoroughly enjoy both.

    • Karen says:

      Hi Charlene, The underlying threads you insightfully detect are at the heart of all my intentions. I’m pleased to have you join me in this little corner of the created life God has given us.

      Your friend,
      Karen

  • Shari says:

    You have truly embraced weaving! So much to discover. When I was visiting my best friend Janet in Austin last October we went hiking at Enchanted Rock. Very special place. Be well.

    • Karen says:

      Hi Shari, I’m so happy to know that my little mention of Enchanted Rock meant something to you. Having had hiked Enchanted Rock a few times, it was very exciting to get to see it from the air!

      Be well to you and yours,
      Karen

  • Linda Adamson says:

    Lovely. How long does it take you to set up your loom? Where did you learn how?
    Linda

    • Karen says:

      Hi Linda, This warp took me a good 12 hours to set up. I was determined to get it done, so I spent about 3 hours, 4 days in a row. I enjoyed the process – it all seems so amazing how the systems work together. But this is why most drawloom weavers put on looooong warps. This current warp is only about 5-6 yards long because this is for planning out designs to use on larger pieces in the future. Besides, I still need the practice of dressing this loom often enough so that I don’t have to start from scratch with my memory.

      I took a drawloom class from Joanne Hall at her studio in Montana. It was excellent!

      All the best,
      Karen

  • Linda Cornell says:

    I enjoy your posts and weaving inspirations! I hardly know what a draw loom is but it’s cool to see what you produce in it! Most particularly, your intertwining of faith through your weaving is mist inspiring. God continue to bless you!

    • Karen says:

      Hi Linda, It wasn’t that long ago that I hardly knew what a drawloom was, either. It’s been an interesting learning journey.

      I’m glad the intertwining of faith through my weaving experiences resonates with you.

      Thank you,
      Karen

  • Connie says:

    All I can say is, WOW! Thanks for sharing.

Leave a Reply


Warp Chains Are Beautiful

The reel spins ‘round, ‘round, ‘round one way, and then ‘round, ‘round, ‘round back the other way. Rhythmic, mesmerizing, and strangely soothing. Counting, as I wind two ends at a time, I find myself whispering “2, 4, 6, 8, 10, 12, ….” The warping reel is one of my favorite pieces of equipment. This warp has seven colors of 22/2 Cottolin for bath towels which are to accompany the hand towels I recently made. I am winding this in four bouts, and there are different color changes in each bout.

Winding a warp for cottolin bath towels.
First bout on the warping reel.
Making cottolin bath towels.
Second bout. Choke ties about every meter keep the ends from shifting as the warp bout is chained and taken to the loom.
Making a warp for handwoven bath towels. Cottolin.
Third bout. Each of the four bouts has nearly the same number of warp ends.
Glimakra warping reel - one of my favorite pieces of equipment!
Fourth bout.

I marvel at the combination of thread colors as I chain each bout off the reel. The warp chains look beautiful. They always do. Warp chains are dreams in the making, where anything is possible. Haven’t you dreamt of handwoven bath towels?

Winding a warp on the Glimakra warping reel.
Came close to running out of thread on some of the tubes. (I did have backup tubes, but not from the same dye lots.)
Beautiful warp chains!
Beautiful warp chains, ready for the loom.

When we listen closely, we can hear the inaudible. Our hearts can hear the softest whisper. “2, 4, 6, 8, 10, 12, …” Even the hairs on our head are numbered by the Grand Weaver who planned our existence. Our days are numbered, as well. And when our heart is listening, we can hear the quiet whisper of the Lord Jesus, “Are you weary and burdened? Come to me, and I will give you rest.”

May you listen for the softest whisper.

Gently,
Karen

9 Comments

  • Beth Mullins says:

    Beautiful colors! I’m looking forward to seeing the warp spread across the reed. Best to you and yours!

  • Nannette says:

    The promise of the future beauty. The beginning of a process that completes at the plans and skills of the weaver. Time will tell.

    I always gorge on your color choices.

    Thank you.

    • Karen says:

      Hi Nannette, There’s always an element of time that holds the promise. I’m glad you enjoy the color choices. Choosing colors one of the most exciting parts about weaving for me.

      All the best,
      Karen

  • LJ Arndt says:

    Beautiful colors, looking forward to seeing the towel sets when they are complete and put together as the sets.

    • Karen says:

      Hi LJ, Making towel sets for our bathroom is something I’ve thought about doing for a long time. It’s nice to see it coming to pass. Thanks for your encouragement.

      Happy weaving,
      Karen

  • Ruth says:

    Karen,
    Thank you for your thoughts about listening to the whispers in our lives. Your words are always a breath of fresh air and I appreciate your reminders to look closely into my life and know that God is working his miracles in the smallest things. Looking forward to seeing your bath towels – wrapping up in a handwoven bath towel is such a luxury!
    Blessings to you and yours.

    • Karen says:

      Hi Ruth, I like your words that God is working his miracles in the smallest things. So true!

      I suppose that handwoven bath towels are a luxury. It’s nice to be surrounded by handwoven articles, simple luxuries.

      Blessings to you,
      Karen

Leave a Reply


Handweaving Dilemma

I am making great progress on my drawloom rag rug, closing in on the final segment. And then, I take a picture and the camera reveals something I had failed to see. A mistake! Here is the dilemma that I’m sure other weavers face, too. It’s an internal dialogue. I can live with the error. Or, can I? No one will notice. Well, I certainly will notice. But I am sooo close to the end. I really don’t want to undo the last forty minutes of weaving. What would you do?

Drawloom rag rug.
Error in the rug escapes my notice.
Mistake in the weaving, exposed by taking a photo.
Photo reveals my mistake.

Back it up. Using the chart that I follow for pulling draw cords, unit by unit, I work my way back until I get to the error. On reflection, doing the task is easier than thinking about doing it.

Removing weft to fix an error.
Backing up.
Single-unit drawloom.
One single unit draw cord makes all the difference. This cord should have been drawn in the affected rows.
Rag weft is taken out to correct an error.
Undone. Weft is removed. The mistake has been taken out.
Drawloom rag rug. Correcting an error.
Ready to start fresh from here.

My feelings can fool me. I don’t feel like going back and correcting my mistake. This is the time to pause and listen. Wisdom is at the door. Wisdom requires thinking, and listening, and time. Time is my friend, if I refrain from hurry. Wisdom is much like the skill of an experienced craftsman—one who understands precision and artistic expression and do-overs. Wisdom knows that patience is powerful. The easiest way to do something often forfeits the greatest rewards.

May you keep your ear at wisdom’s door.

Peace,
Karen

14 Comments

  • Such a wonderfully wise decision and if anyone can do it – make that small mistake go away and result in a perfect weave – you can and DID! I am always so inspired by your work, and follow along with great joy! Thanks for sharing – inspiring as always!
    Will you tell me what the blue cloth is? So beautifully bold and it looks like a hand dye or print. I am a fairly new weaver and love experimenting and making rag rugs.

    • Karen says:

      Hi Bethany, One of the best things about making rag rugs is getting to play with beautiful fabrics. There are two different blue fabrics here. They alternate. One is a solid blue with some variance in color, and the other is a small bright floral print. Both are 100% cotton quilting fabrics that I have left over from other rag rug weaving projects. Combining the two fabrics makes the blue very rich.

      Thanks for your kind words!
      Happy weaving,
      Karen

  • Charlotte says:

    Wisdom and patience and un-weaving prevailed. 40 minutes of weaving taken out. Wise! You would have spent the lifetime of the rug with your eye going to the mistake. Wisdom…a wonderful gift to us! He perfects us only a daily basis, if we allow. Always, I seek His wisdom and ask that He bless the work of my hands. This oftentimes means…un-weaving due to my mistake. I began weaving my sheep, late yesterday. When I removed the temple, I realized one had only 3 legs. You know the rest of my story….

    • Karen says:

      Hi Charlotte, Yes, if I had kept going (and I came so close to doing that), I would always have seen that one spot on the rug.

      Oh, yes, I know the rest of your story. Another lesson learned.

      Love,
      Karen

  • Donns says:

    I just faced the same dilemma. Something didn’t look right after several inches of weaving a project from Handwoven. So I stopped and googled “Handwoven corrections 2019” and sure enough there was a correction to the draft. I had to walk away and let it all sink in before I could unweave and then decide how to proceed. As I always tell myself, it’s only time.

    • Karen says:

      Hi Donns, Wise words – “it’s only time.” Time is something we all have. I’m glad you caught the mistake while you could still do something about it.

      Happy weaving,
      Karen

  • Nannette says:

    Wisdom…. A blessing to take another look before proceeding. I’ve learned so much from walking away to clear my head… Then when I return, the mistake is obvious.

    Is wisdom what happens between finishing and enjoying the journey?

    Blessings upon your journey.

  • Betsy says:

    Isn’t that always the way? It’s soooo difficult in our minds, but easy once we actually do it. Happens over and over to me.

    Can’t wait to see this off the loom!

    • Karen says:

      Hi Betsy, I don’t know why I have to learn the same lesson over and over. Oh, for wisdom and patience to sink in.

      It will be a few more days, now, but I’m near the end of the rug.

      Happy weaving,
      Karen

  • Allison says:

    You are right, taking it out actually takes less time than thinking about taking it out!

    • Karen says:

      Hi Allison, Next time, maybe I will just do it instead of thinking about not wanting to do it. It sounds like you’ve been there, too.

      Happy weaving,
      Karen

  • Yvonne Taylor says:

    Well I would just take a large darning needle anf go over the mistake and hide the ends. You will be more careful from now on Im sure. Ha ha. Who hasn’t done something like this?

    • Karen says:

      Hi Yvonne, Trust me, I considered doing just that. And I will probably need to darn other mistakes that I’ve missed. But I’m glad I went back to fix the error now. Easier, really, than covering it up later.

      I think we’ll all done something like this, haven’t we?

      Happy weaving,
      Karen

Leave a Reply


What to Do with Linen Leftovers

These waffle-weave washcloths are made out of my linen leftovers. For years, I’ve been saving linen scraps: the small amount left on the tube, quills that weren’t used up, thrums that I couldn’t bear to discard, and skinny warp chains from the times I accidentally wound a few extra warp ends.

Using linen leftovers for a new warp.
To make this warp, I finished off about a dozen tubes that had small amounts of 16/2 linen.
Winding a linen warp.
Putting leftover threads together.

The warp is 16/2 linen. I alternated two colors at a time in the warp, so there are interesting color-and-weave effects that outline the “waffles” in the weave.

New linen warp.
Heddles are threaded in point twill for waffle weave, alternating two colors at a time.
Afternoon sun on a new warp.
Afternoon sun is a pleasant sight on a new warp.

The linen for the weft is everything from fine 16/1 line linen to coarse 8/1 tow linen. I am purposely leaving weft tails exposed. I expect significant shrinkage, so I will trim the tails shorter after wet finishing.

How to use linen leftovers.
Linen “weft-overs” include thrums, end of tubes, and accidental warp chains.

Ideas for this project originated with Clean with Linen, by Sanna Ignell in Väv 2016 No.2, p.6, and Handtowels made of linen, by Elisabet Jansson in Happy Weaving from Vävmagasinet, p.31.

Linen waffle weave.
Linen waffle weave.

Do you have precious leftovers you’ve saved from your journey through life? Memories we don’t want to lose. And memories we wish we could forget. All these leftover threads serve as reminders that we are meant for more than what we can produce on our own. Here’s the good news. Love invites us to hand over our collection of scraps. Listen to Love. His name is Jesus. He takes our linen discards, and, with nothing wasted, weaves his beautiful story of redemption in us.

May your leftovers be given new life.

Love,
Karen

14 Comments

  • Joyce Lowder says:

    Beautifully said, Karen! And great idea! 🙂

  • Robin says:

    Fantastic idea!
    Would love to see pix of the finished wash cloth. Perhaps a future post?

    • Karen says:

      Hi Robin, Thanks for giving your thoughts! I will be happy to show pictures of the wash cloths when they are finished! I’ll be as surprised as you at the results. I expect to get 10 wash cloths from this warp, so hang on, it may take a while.

      Happy weaving,
      Karen

  • Nannette says:

    An album quilt I made for my daughter’s wedding was cobbled together of the obvious dress fabric from her childhood, but also needle work from her ancestors. Textiles too fragile to use as originally designed, but reinforced and added to the beauty of the quilt designed for the next generations to come.

    One block included a piece of weaving done on a home made loom by my husband’s grandmother.

    Leftovers from earlier generations kept to build something useful and beautiful.

    Nothing goes to waste in God’s world.

    • Karen says:

      Hi Nannette, Your quilt sounds fantastic. What a wonderful gift, full of meaning.

      “Nothing goes to waste in God’s world.” Amen!

      All the best,
      Karen

  • Linda Cornell says:

    Beautifully said!

  • Laurie says:

    Is that a plainweave hem? Does it contract the same as the waffleweave?

    • Karen says:

      Hi Laurie, Yes, I am doing a plain weave hem. I am sure it will not contract the same as the waffle weave. I expect the hem to look a bit wavy. Since this is my first time to do waffle weave, I’m waiting to see what it does for sure. 🙂

      Happy weaving,
      Karen

  • Charlotte says:

    I cannot believe, yet I must! The timing of your post – waffleweave wash cloths to my drawdown for the next project – waffleweave wash cloths! Isn’t this fun?!?!?!
    Mine will be 12/6 seine twine. The warp on the drawloom is nearly tweaked for a new run of Casita bath towels – Cottolin. The wash cloth warp will go on Julia once my Marines have come and gone. Also, for the Casita.

    The Inkle loom is warped for the hang loops…it’ll go to the mountains with us.

    Oh how I love the direction of our path and sharing it, such a sweet gift!

    • Karen says:

      Hi Charlotte, How fun! And believe it or not, yesterday I finished the drawdown for my next project on the Standard – Cottolin bath towels! Wow, you and I are really in sync.

      Love,
      Karen

  • Betty Morrissey says:

    HI!
    Can’t’ wait to see them. Love how everything finds its purpose.

    • Karen says:

      Hi Betty, With purpose there’s hope. And we all need hope. I’ll keep you posted on the progress and finishing of these washcloths. Stay tuned…

      All the best,
      Karen

Leave a Reply


Drawloom Cords and Handles

My first drawloom warp used ten pattern shafts, which was plenty. I have now installed the cords and draw handles for all fifty pattern shafts, so the sky’s the limit! (See Process Review: First Drawloom Warp)

Adding draw cords to the drawloom.
Adding draw cords. I stand on the foot beam to reach up to the top of the draw frame to pull cords through the holes.
Draw cords are added in order.
Draw cords are added in order.

Adding all these draw cords and handles is a big job. It involves a cord threader and scissors and time—reaching, going back and forth, measuring, cutting, tying. Over and over. It’s not hard, but it seems endless. Yet for some strange reason this job is entirely enjoyable. I feel like an architect and builder, a dreamer and investor. It’s incredible to step back and see the structure that this effort has produced. And this is merely the set up. Can you imagine the weaving prospects?!

This is how we build good structures in our lives. Intentional, persistent, focused. Listen well. Over and over. The way we speak makes a difference in the way we listen. When we speak with grace, seasoned for the hearer, we ready ourselves to listen. Our cord threader is our unselfish attentiveness to pull someone else’s thoughts and questions toward our understanding. With this beautiful structure we are ready for anything. Accomplished through the grace of God, the sky’s the limit!

Drawloom ready for weaving!
Drawloom with fifty draw handles, a sight to behold.

May your words be seasoned with grace.

Getting ready,
Karen

15 Comments

  • Beth Mullins says:

    Looks so complicated!

    • Karen says:

      Hi Beth, I know it looks complicated. That’s what I always thought. I’ve been surprised to learn that it’s actually a series of simple steps to set this up.

      Happy Weaving,
      Karen

  • Nannette says:

    Oh, my goodness. The loom set up is a piece of sculpture. Precision. Symmetry one view. Asymmetrical from another direction. Soooo beautiful.
    Function that is a finely tuned instrument.
    Thankful for sharing.
    Nannette

    • Karen says:

      Hi Nannette, Yes, It is a piece of sculpture. A fluid sculpture. You’ve given it a beautiful description.

      All the best,
      Karen

      • Nannettte says:

        At one o’clock this morning I finished weaving up the last of the rag on the overshot warp. The plan was to cut off the 3 rugs and re-tie the warp to use to explore tapestry as described in one of your more recent blogs.

        Curmugeon66 uses a stick to stabilize the woven edge until it can be machine hemmed. So… I pulled out a stick. Put it on the beater bar while I pulled the 3 rugs from the loom.. You know where I am going with this.

        By the time I heard the stick hit the treadles, hours of carpet warp had been pulled from the reed. It was hot and sticky and I was tired.

        This morning’s Sound Bites daily devotional title was ‘Paying Attention’.
        Today’s plan is to put a sewing machine hem on the rag rugs and pack them up to take to the future retirement home.

        There is nothing else to say… Well maybe “Praise God”

  • Lynette says:

    Please send more posts on how it works! Will be eager to see! Also, how wide of a Glimakra Standard Loom is needed to fit all 50 pattern shafts? (Minimum width) It looks like it will be fun.

    • Karen says:

      Hi Lynette, I will post my progress with this loom. My Glimåkra Standard is 120cm (47”), but I think this same draw frame fits on a smaller Standard or Ideal—maybe 100cm (39”). Someone who knows for sure can comment on this to verify.

      It will certainly be fun! That I know.

      Happy Weaving,
      Karen

  • Arlene Favreau-Pysher says:

    I love the spiritual aspect of weaving and being that listener…. and incorporating the other person into our being …thank you for your post. Arlene

    • Karen says:

      Hi Arlene, Thanks for your thoughtful words!

      I’m so grateful for the Lord’s grace to show us how to make others more important than ourselves.

      All the best,
      Karen

  • Annie says:

    That whole set up just boggles my mind! Nannette’s description is perfect!

    Hopefully, I will have an opportunity to come see this in person one day, Karen.
    In the mean time, I am looking forward to some videos of you weaving with this.

    50?! I really don’t know if I could keep that all straight!

    • Karen says:

      Hi Annie, It’s my hope to make some short videos of the drawloom. Thanks for the prompt.

      Yes, 50 pattern shafts. That means 50 handles to pull. The more, the merrier!

      All the best,
      Karen

  • Judy says:

    Karen thank you for your posts on the drawloom. I have an old countermarche loom that I would love to build a drawloom for. I find this very interesting and can’t wait to see what you do with it. I have taken a basic drawloom course. You have inspired me to get started.

    • Karen says:

      Hi Judy, How wonderful that you are dreaming of building a drawloom for your countermarch! Dreams are where the action begins!

      Happy Weaving,
      Karen

  • Keri Mae says:

    Beautiful post!

Leave a Reply
