Tried and True: Checklist for Winding a Warp

I am winding a narrow warp for my next drawloom project. My warping reel is in a little four-foot-by-four-foot corner of my drawloom studio, and has just enough room to maneuver. When I am ready to wind a warp the first thing I pull out is my trusty checklist. I use a checklist for efficiency. It keeps me on track. And it’s more dependable than my memory.

Checklist for Winding a Warp

__ Weigh warp thread and write the amounts on the project notes. By weighing the thread before and after a project, you will know exactly how much warp thread was used in the project.

__ Stick a sample four-inch thread to each thread label; put a rubber band around the tube. After you finish winding the warp, you can quickly pair each yarn with its correct label because of the sample thread stuck to the label.

__ Bring supplies to the warping reel. If your warping reel is in a different room, or in a separate building, like mine is, make sure you have all you need before you head to the warping reel.

+ Thread for the project

+ Thread stand, if not already in place

+ Scissors

+ Choke ties

+ Project notes, with fully completed draftAn incomplete draft may give faulty information. Also, a review of the project notes and draft is a good idea, especially if weeks or months have passed since you wrote it all down.

Checklist for winding a warp.

__ Set up the warping reel for warp length. Use a guide string, or measure the distance needed to place the pegs and turning pin at the right place on the warping reel for the warp you are going to wind.

Checklist for winding a warp.
Checklist for winding a warp.

__ Set out the thread on the thread stand. Wind the warp with two or more threads at the same time, for best results.

__ Hang or tape up the project notes at eye level. Project notes show the warp sequence and other vital information.

__ Take note of warp length, number of bouts, and number of ends in each bout. Aim for 25 cm (10”) or less in the reed, or 200 or fewer ends, per bout. For the drawloom, wind the warp in pattern unit increments when possible.

Checklist for winding a warp.

__ Wind first bout, counting warp ends. Use a cord between groups of ends to keep track of the counting.

Checklist for winding a warp.

__ Visually check the warp order. Check to see that the warp order on the warping reel matches the warp sequence on the project notes. (I added this step to my checklist after the time I omitted 6 threads at the center of a warp, discovered after threading the loom.)

__ Tie off around the turning pin or the outside peg. Always wind the last pass with two or more threads together so you can tie them around the pin or peg.

__ Tie the lease cross; and tie choke ties on the warp. Tie the cross first, and tie any passes of the warp directly above the cross. Then, spin the wheel and tie the warp wherever it passes on the side opposite the cross. Also tie at the turning pin, at the top and bottom of the loop.

Checklist for winding a warp.

__ Chain the warp bout. Start the chain by holding the loop at the turning pin, and pull out the pin. Chain the warp, ending at the cross. (I use my knee, not so gracefully, to control the turning of the reel as I chain the warp.)

Checklist for winding a warp.

__ Place the warp bout on the loom, with the lease cross end going through the beater.

__ Wind remaining bouts, following the same procedure. When you place the warp chain on the loom double check the warp sequence to make sure the bouts are in the right order.

Checklist for winding a warp.
Checklist for winding a warp.

__ Roll up the thread tubes, replace labels, weigh thread and write down amounts, and place thread tubes in project bin. Each loom has its own project bin to hold the thread for that project.

Checklist for winding a warp.

__ Put away the choke ties, scissors, and thread holder.

__ Fold up the warping reel.

Checklist for winding a warp.

Get ready to dress the loom!

Checklist for winding a warp.

May you enjoy the process.

Happy Weaving,
Karen

10 Comments

  • Elisabeth says:

    Thank you so much! I realize it has been awhile, long enough to forget the steps. I’ll wind a warp today following these instructions. Then I will have two towel warps and can hopefully dress the loom without my usual long pause I’ll weave the easy one first, to get back into it, and have as a goal to have some towels ready as Christmas gifts.

    • Karen says:

      Hi Elisabeth, I’m glad you can use this! A checklist really helps me when I’ve been away from the loom for a while. I don’t have to re-think everything. I’m looking forward to hearing more about your towels. They will be beautiful, I’m sure!

      Happy weaving,
      Karen

  • Betsy says:

    Ah, yes, tie the cross. I don’t know how many times I’ve come *this close* to forgetting that step.

  • Karen Simpson says:

    Thank you so much….I’ve never weighed before to determine usage amount…will do. I also number my bouts with a sticky…learned the hard way..ha….

    • Karen says:

      Hi Karen, I’ve learned a lot of things the hard way, too. 🙂 I also weigh my weft thread before and after. The accumulated data helps when planning new projects.

      Happy weaving,
      Karen

  • Barbara says:

    I use a different color tie at the top of the lease cross so I know which way is up when taking the warp bout to the loom. Got confused once with a striped warp, took a bit of “undoing” to be sure I didn’t have the same colored stripes next to each other.

    • Karen says:

      Hi Barbara, Thanks for sharing your helpful tip. Getting the warp bouts mixed up at the loom is not fun. Some of our best lessons come through fixing our mistakes!

      Happy weaving,
      Karen

  • Summa Irukalam says:

    This is terrific! Thank you.

Leave a Reply


Tried and True: Organized Reeds

My weaving history includes very fine threads all the way to heavy-duty rug warps. As a result, I have acquired a wide selection of reeds over time. All five of my looms have beaters that will accommodate any length or height of reed. When I plan a project, one of the first things I consider is whether I have the size reed that is needed. To keep my reeds organized, I need two things. One, a simple method to manage the reeds I have, tracking the reeds as they go in and out of use. Two, a place to store all the reeds, arranged in order by dents per cm and dents per inch.

Reed Organization

  • Reed Inventory

I keep a list in my Notes app on my phone with the sizes and lengths of reeds that I have. If a reed is in use, I note which loom. If a reed will be needed for a planned project, I also note that. As soon as I remove a reed from the beater at the end of a project, I put the reed away and update my Reed Inventory list.

Simple system for tracking reeds in and out of use.
Sample Reed Inventory note. When I am planning, I look at the note on my phone to see what reeds I have that are available. “Next” reserves the reed for the loom that needs it next.
  • Reed Holder

Steve created a storage solution for my reeds. The holder goes along the back wall of my drawloom studio for about six feet. Here are the details, using nominal board sizes. The reeds sit on a 1” x 6” board at the base, which is supported against the wall by a 1” x 4” board. The base, with a 1” x 2” lip, sits about 12” off the ground. The reed dividers are 3/8” x 5 3/4” dowels that are sunk into a 1” x 3” board that is attached to the wall, which sets the dowels about 27” above the base.

DIY Reed Holder behind my drawloom.
Reed holder is fastened to the wall behind the drawloom. (Notice that the drawloom rag rug warp has come over the back beam…)
Organized reeds!
The dowels are placed at a height that will hold even my shortest reeds.
Reed holder stores weaving loom reeds. DIY
Reeds are in order by dent size. Metric reeds are separate from those with dents per inch.

If you would like a PDF copy of Steve’s diagram that shows all the dimensions, click HERE to send me an email request.

May you have a place for everything, and everything in it’s place.

Yours,
Karen

8 Comments

  • Geri Rickard says:

    That handy husband of yours! What a nice solution, and I like the pegboard with hanging lams, etc. very nice,

  • Marianne says:

    Thanks for sharing! Weaving requires so much paraphernalia so i am always curious how other weavers organize their studios. Thank you you for inviting us into yours!

    • Karen says:

      Hi Marianne, Yes, paraphernalia is a good description of all the tools and supplies needed for weaving. Learning ways to organize things seems to be a requirement for weaving.

      Happy weaving,
      Karen

  • Betsy says:

    Ha! In the first picture of the storage rack, I thought it was attached to the wall at an angle, with the shortest reeds on the right. Nice optical illusion. And very nice storage solution.

  • Elisabeth says:

    Very neat idea! I agree, it’s so helpful to have a good system for storing tools and accessories. Thank you for sharing!
    Elisabeth

    • Karen says:

      Hi Elisabeth, It’s much more relaxing to have everything in its place. And it saves money because I’m not buying duplicates of things I already have, but couldn’t find.

      Thanks!
      Karen

Leave a Reply


Happy Ending Rag Rug Warp

Welcome to my weaving studio, which doubles as our home, I said, as they walked up to the front door. Our luncheon guests were introduced to the weaving environment of the Texas hill country home that Steve and I enjoy. Our time together was refreshing, filled with lively conversation over a home-cooked meal, complete with discussions about looms, threads, and like-minded pleasures.

Lunch with honored guest, Joanne Hall.
Steve and I enjoy lunch with honored guest, Joanne Hall, and a few members of the San Antonio Handweavers Guild.
Karen, Janis, Joanne Hall, Henriette, Vesna, and Cindy.

Six rosepath rag rugs encompass the cloth beam, with the back tie-on bar just inches behind the heddles. It seems only fitting that the woman who gave me my first rosepath rag-weaving experience should be given the cherished scissors for this momentous occasion. Joanne, will you do us the honor of cutting off? I couldn’t have wished for a happier ending of this warp.

Joanne Hall does the honor of cutting off the rag rugs.
Joanne Hall, ready to cut off the rag rugs.
Cutting off rag rugs.
Cutting off.
Unrolling the cloth beam with new rosepath rag rugs.
Unrolling rugs from the cloth beam.
Six new rosepath rag rugs, ready for finishing.
Six new rosepath rag rugs, ready for finishing.

We all have wishes, some of which we make public, and some remain as closely-held secrets. It’s those deep wishes that make us who we are. God knows your name. He knows your deep desires. One day, all our secret wishes will be rolled out like a stretch of rag rugs for the Maker to examine. Amazingly, he offers grace to cover the wrongs. And He embroiders his Name on the hand-crafted souls that belong to him.

May your cloth beam keep filling up with deep-hearted wishes.

Your friend,
Karen

6 Comments

  • Geri Rickard says:

    Just beautiful, and your weaving studio/home is lovely! What fun having Joanne there!

  • Janis Schiller says:

    Thank you to you and Steve for a splendid day in the Hill country. And your rugs are lovely (as are so many other pieces in your home ). You have a great eye for putting colors together.

    • Karen says:

      Hi Janis, We sure enjoyed having you. I appreciate your kind compliments. I do get a thrill from putting colors together.

      Happy weaving,
      Karen

  • Nannette says:

    Straight selvages. Even rows. Woven hems with a little ripple to compensate for the shrinkage. And, oh the colors!!! Combinations that pull me in to take a closer look. Beautiful.

    My husband is now t-minus 10 months to retirement. My floor loom is dismantled. Pieces leaning against the wall in a space 2Xs what the warping board takes. A couple milk crates of warp. Two airtight totes holding my books and supplies collected over the decades.

    Not much considering all the beauty such a small space can and has created.

    I am staying put for the next month. Grandbaby #3 is going to meet us by April 3rd.

    Until then… Your wonderful posts will feed my weaving creativity.

    Thank You

    • Karen says:

      Hi Nannette, Step by step, things come back together again. Enjoy the process. And congratulations on the coming new family member.

      All the best,
      Karen

Leave a Reply


Process Review: Drawloom Jewels

It is exciting when Maverick walks by. Although he never comes in my drawloom studio, he does stop for a moment to look my way. You’ll see him in the slideshow video below. But what happens inside the studio is even more exciting, especially when it’s time for cutting off!

Drawloom with 16 pattern shafts.
Drawloom, set up with sixteen pattern shafts. I graph out the designs in Excel on my computer. Then, I print out the gridded pattern to use at the loom. I keep my place in the pattern with a magnet and magnet board made for cross-stitch embroidery.

This is Tuna wool, so I expect some shrinkage, but how much? I take careful measurements before and after wet finishing. Besides the main piece of fabric that I’m using for a garment, I have two sample pieces. I can experiment with the samples before wet finishing my garment fabric.

Here are my findings:
Sample 1. Hand wash and air dry.

10% shrinkage in width; 13% shrinkage in length.

Sample 2. Machine wash (3 minutes agitation on a gentle cycle, with a short spin) and machine dry (low setting) till damp, finish with air drying.

13% shrinkage in width; 14% shrinkage in length.

~How to do the shrinkage calculations~
First measurement (on the loom) minus the second measurement (after washing and drying) equals the difference. The difference divided by the first measurement equals the percentage difference.
For example, 50 cm – 43.5 cm = 6.5; 6.5 / 50 = 0.13; 13% shrinkage.

The first sample fabric is softer than the unwashed fabric, but not as soft as I’d like. The second sample fabric is beautifully soft, like a nice warm sweater. So, with confidence, I wet finish the garment fabric—with great results. It’s perfect for the fall/winter vest that I’ll soon be wearing, made from this fabric!

Wool garment fabric from a drawloom.
Like a sweater, this soft fabric will be comfortable to wear.
Making a pattern for handwoven garment fabric.
Muslin pattern for a simple vest. First, I’ll make a vest out of a wool throw, woven on my rigid heddle loom ages ago. Then, I will cut into the new drawloom fabric, with confidence about the fit.

Enjoy this photo show of the drawloom process.

May you enjoy the process you’re in.

Happy Weaving,
Karen

6 Comments

Leave a Reply


Weaving through The Big Book

It took me seven years of study, practice, and mistakes to complete this rigorous Swedish weaving curriculum! You have been with me through much of it right here. I’m talking about The Big Book of Weaving, by Laila Lundell. I made it through the book, sequentially, page by page, warp by warp. 43 warps in all! Remember the blue 12-shaft double-weave blanket I had on the loom in June? That is the final project in the book.

Handwoven double weave blanket. 12 shafts.
Double-weave wool fabric is ready for wet finishing, where it will be transformed into a soft, cozy blanket.

In the short video below, each completed project is presented in order in our Texas hill country home. Watch to the end to see the blue blanket in all its finished glory.

For nitty-gritty details, check out The Big Book of Weaving tab at the top of the page.

I. Secrets to success:

  • mindset of a student
  • determination
  • eyes on the goal
  • no option other than completion

One loom dedicated to the book.


II. Lessons learned:

  • technique
  • processes
  • planning
  • drafting
  • Swedish practices

Any mistake can be remedied.


III. Treasures gained:

  • patience
  • humility
  • endurance
  • focused attention
  • problem solving
  • creative freedom

Confidence.


IV. Prized perspectives:

  • new experiences
  • delight of dressing the loom
  • wonder of cloth-making
  • fresh ideas
  • joy of discovery
  • knowledge and understanding of the loom

Getting lost and absorbed in the whole process of weaving.

V. Favorite project: Old-Fashioned Weaving / Monksbelt (at 4:46 in the video)

Are we determined students of heavenly things? Oh, to know God’s will! Study what’s written, don’t lose heart, eyes on the prize, no option besides completion through Jesus Christ. One life dedicated to know him. Day by day, warp by warp, the Grand Weaver teaches us. We can know God’s will.
